CORE 8 FLEX - Q-SYS network + analog I/O processor
The Core 8 Flex audio, video and control (AV&C) processor extends the applications of the Q-SYS Platform into a wider range of smaller-scale installations across corporate, higher education, healthcare and beyond. Built on the same foundational technologies and driven by the same Q-SYS OS as the rest of the Q-SYS processor portfolio, including the best-in-class Q-SYS Core 110f, Core 8 Flex is designed for applications with lower network or analog channel capacity and/or targeted processing requirements.
Q-SYS Core Processor with 8 local audio I/O channels, 64x64 network I/O channels with 8x8 Software-based Dante license included, USB AV bridging, dual LAN ports, VoIP telephony, 8x8 GPIO, 8 AEC processors, Half-size 1RU. Includes Scripting/UCI functionality.
Features & Benefits
64 x 64 networked audio channels (Q-LAN / AES67)
8x on-board Flex channels and GPIO
8x AEC processors
up to 32 x 32 Dante audio channels (8 x 8 included)
USB AV bridging (8 x 8 audio + Q-SYS camera support)
Full-featured Q-SYS Control engine (with optional feature license)
External USB audio device host
Up to 2x VoIP instances
1U half-width, includes mounting hardware
Network plus on-board I/O
In addition to its 64 x 64 network I/O capacity, the Core 8 Flex offers eight on-board Flex channels and eight GPIO on-ramps to integrate analog audio and control devices into the Q-SYS Ecosystem. Ideal for in-room processing with both analog & networked endpoints.
