AD-P.SUB-BK - 6.5-inch Dual Voice Coil, Small Format Pendant Subwoofer (Black)
The AD-P.SUB is part of the AcousticDesign™ Series SUB/SAT loudspeaker solution, which is ideally suited for background music applications that require depth and clarity even at lower volume settings. The AcousticDesign Series SUB/SAT loudspeakers are specifically designed to be mix-and-match capable; meaning any combination of satellites may be paired with any subwoofer in the AD Series SUB/SAT line.
6.5" Dual voice-coil pendant subwoofer, provides High-pass output for up to four (4) satellite speakers, 70/100V transformer with 4Ω bypass, includes cable and fasteners for suspended installation. Color - Black.
Features
Dual voice coil for improved thermal dissipation and higher output
Low saturation and low-loss 70 / 100 V transformers with 4 Ω bypass
4x built-in high-pass filtered outputs
Snap-fit magnetic grills
Locking 4-pole Euroblock connectors
2x quick link cable assemblies and slip-lock fasteners supplied
Intrinsic Correction™ voicings available via MP-M Series mixers and Q-SYS Platform
Available in black (RAL 9011) or white (RAL 9010)
UL1480 certified
Specifications | AD-P.SUB |
LF transducer | 6.5-inch (165 mm) dual voice coil weather treated paper cone woofer |
HF transducer | N/A |
Effective frequency range | 55 Hz – 150 Hz |
Rated noise power / voltage | 100 W / 20 V (rms) |
Sensitivity [dB] (rated @1 W, 1 m) | 86 |
Coverage (-6 dB) | Omni |
Directivity factor | TBD |
Directivity index [dB] | TBD |
Maximum SPL [dB] (continuous / peak) | 100 / 106 |
Recommended amplifier | 100 W |
Transformer taps / impedance | Bypass:4 Ω |
Connectors | Mono input: 4-pole Euroblock with thru output |
Enclosure material | ABS |
Grille material | Powder coated steel |
Ingress protection | IP-34 |
Operating environment | Designed for indoor use |
Operating temperature range | -4 to 122° F (-20 to 50° C) |
Net weight | 16.5 lb (7.5 kg) |
Product dimensions (Ø x H) | Ø 13.6 x 13.8-inch (Ø 4.3 x 4.5 mm) |
Shipping weight | TBD |
Shipping dimensions | TBD |
Included accessories | 2x cable rigging, 3x Euroblock connector, 2x sealed input cover, grill |
Safety agency | UL1480, Transformer UL registered per UL1876, ROHS, CE compliant |
As part of QSC's ongoing commitment to product development, specifications are subject to change without notice.
