MCDJ - Single Zone Music Server
The effortless way to fill every room with incredible sound.
MC-DJ blends audiophile quality with everyday ease. Start music in any room, control the vibe in every zone, and enjoy a system that just works—beautifully. Powered by Lyrion Music Server for lightning-fast browsing and reliable playback.
The effortless way to fill every room with incredible sound.
MC-DJ blends audiophile quality with everyday ease. Start music in any room, control the vibe in every zone, and enjoy a system that just works—beautifully. Powered by Lyrion Music Server for lightning-fast browsing and reliable playback.
Part 1 — MC-DJ (the heart)
MC-DJ includes a world-class built-in music server powered by Lyrion—the industry’s gold standard for speed, reliability, and sound quality. Enjoy native playback from Spotify, Pandora, TIDAL, Deezer, Qobuz, TuneIn, and many more. Control every stream from your home-automation system without app-surfing.
Note: Amazon Music and Apple Music are supported via AirPlay 2 directly to MC-DJ or any MC-Playa.
- Powered by Lyrion for snappy browsing
- Ultimate control from ELAN / Control4* interfaces
- MC-DJ app + Customer Interface + MCGUp to 32 players in one system
art 2 — MC-Playa (the everywhere player)
Each MC-Playa can seamlessly assimilate into the MC-DJ swarm for synchronized playback—or operate independently over the network using AirPlay 2 or Spotify Connect. Perfect for guest control and casual listening.
- Great for parties, playlistspodcasts, an
- Independent or grouped in one tap
- Wired networking for rock-solid streams
- Per-room volume & quick room pickers
- d
Performance & connectivity
- Quad-core 1.2 GHz ARM (Allwinner H3) with 1 GB DDR3
- 8 GB eMMC onboard, plus microSD expansion
- Gigabit Ethernet for rock-solid multi-room sync
- HDMI 1.4 video out; 3.5 mm A/V combo jack
- 40-pin GPIO with I²S/PCM & S/PDIF-Out for audio expandability
- Compact 65×60 mm board, 5 V/2 A power, −20 °C to 70 °C
Audio quality
- TI PCM5102A DAC stage for clean, detailed playback
- Up to 32-bit / 384 kHz PCM support
- Dynamic range ~112 dB; SNR up to 120 dB
- THD+N ≈ −93 dB (@ −1 dBFS)
- DirectPath™ 2.1 VRMS output; no DC-blocking caps required
- Optional IR receiver for simple remote control
